New - IPG Photonics, IPG-18317 - v3 Laser Cube

new icon





Check out our new IPG Photonics, IPG-18317 v3 LaserCube!

It just added to the Metal Fabrication Division to improve thru-put and to add to our capabilities.

Excellon hs 1l ds

Specifications

  • 4 kW Power fiber laser - IPG Photonics LaserCube
  • High-accuracy linear motor-driven X&Y-stages & ball screws driven Z in an H-gantry configuration
  • Granite & welded-steel foundation
  • Working area: 1225 mm x 1225 mm (48.2" x 48.2")
  • Maximum Speed: Cutting - 1000 mm/sec (2362 in/min)
  • Accuracy: Positioning Repeatability - ±25 μm (0.001 in) Positioning Accuracy,  < 10 μm (0.0004 in) Repeatability
  • Materials: Stainless/ Mild Steel, Aluminum, Brass, Copper, Laminated Foils
